The current that did not return.

Why can a small leakage trip a device carrying a large load?

Setting up the mechanism…

Residual current: 0.00mA
Outgoing current before trip: 0.000A
Returning current before trip: 0.000A

Contacts: Closed

Fit the differential sensor and linked contacts

Why can a small leakage trip a device carrying a large load?

Live and neutral pass through one magnetic core in opposing directions. Equal currents cancel; their difference drives the trip mechanism even when the load current is ordinary.

Iresidual = |Ilive − Ineutral|

What this model simplifies

Illustrative 30 mA residual-current threshold, not a safety-device certification. This detects current imbalance rather than thermal overload; timing and different RCD waveform classes are omitted.

Read the source · openstax.org ↗
