Water and blood pass opposite ways.

Why send blood against the water?

Setting up the mechanism…

Water outlet oxygen potential: 1.00
Blood outlet oxygen potential: 0.00

Fraction of inlet difference transferred: 0.23

Fit the specimen and set conditions before running.

Why send blood against the water?

Opposite flows retain an oxygen-potential difference along a gill lamella. The oxygen gained by blood equals oxygen lost by water in this equal-capacity specimen.

εcounter = NTU/(1+NTU); εparallel = (1−e⁻²ᴺᵀᵁ)/2

What this model simplifies

Equal-capacity passive exchanger; NTU describes area/conductance. Oxygen potentials are normalized comparable driving variables, not blood or water concentrations. No oxygen is created.

Read the source · openstax.org ↗

Put it to work.

Transfer more than 60% of the inlet oxygen-potential difference.

Make it work.

Compare oxygen transfer with opposite and parallel flows.

Run

Fine adjustments 4

Exchange conductance / flow capacityNTU

Opposite flows: 1 yes, 0 parallel

Water inlet oxygen potential

Blood inlet oxygen potential

Water and blood pass opposite ways.

Why send blood against the water?

Loading the experiment…
